Leuze Electronic

Leuze Electronic MLD510-RT3 Multiple Light Beam Safety Device Set

Leuze Electronic MLD510-RT3 Multiple Light Beam Safety Device Set

€925,65incl. VAT
€765,00 excl. VAT

المخزون: 1
Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
BrandLeuze Electronic
ModelMLD 500 Series (MLD510-RT3 Transceiver & MLD-M003 Deflecting Mirror)
TypeMultiple Light Beam Safety Device Set
Part Numbers

66537200 (MLD510-RT3 Transceiver - Active Unit)

66500200 (MLD-M003 Deflecting Mirror - Passive Unit)

Technical Specs
System Operating ConceptActive/Passive design
Safety Integrity ParametersType 4
Number of Beams
Beam Spacing400 mm

Operating Range (Scanning Distance): 0.5 to 6.0 m

Light SourceInfrared LED, 850 nm wavelength
Core Functional ModesAutomatic restart mechanism
Response Time25 ms max
Restart Delay Time100 ms

Electrical Connection Type (Active Unit): M12 connector, nickel-plated brass, 5-pin configuration

Safe Outputs (OSSDs)2 x Safety-related switching transistor outputs (OSSDs) with short-circuit and cross-fault monitoring (PNP, Transistor type)

Output Switching Voltage / Current: 24 V DC, max. 380 mA per channel

Diagnostic IndicatorsFront-facing LED status tracking array on transceiver
Structural Body MatrixExtruded aluminum housing finished in Safety Yellow (RAL 1021)
Lens Window MaterialHigh-impact PMMA plastic cover
End Cap Structural ProfileRigid diecast zinc end blocks
Mounting SystemIntegrated side-groove channels accepting sliding T-nuts or heavy-duty rear swivel mount brackets

Operational Ambient Temperature Range: -30°C to +55°C

Storage Ambient Temperature Range: -40°C to +75°C

Enclosure Protection ClassIP67
Weight2.1 kg x 2pcs.
Dimensions90 x 600 x 55 mm x 2pcs.
Country of OriginGermany
HS Code8536.50.90
