Festo CPV10-M1H-5LS-M7 Solenoid Valve - 161414

Festo CPV10-M1H-5LS-M7 Solenoid Valve - 161414

€70,18incl. VAT
€58,00 excl. VAT

Lager: 1
Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
BrandFesto
ModelCPV10-M1H-5LS-M7
TypeSolenoid Valve (CPV Valve Terminal Series)
Part number161414
Technical specs
Output function5/2-way, monostable
Electrical designElectrical actuation via CPV valve terminal slot base
Voltage24 V DC
Temperature-5...50 °C ambient operating temperature range
Power consumption0.6 W
Short-circuit ProtectionYes
Overload ProtectionYes
Reverse Polarity ProtectionYes
FunctionHigh-density directional control of compressed air for automated pneumatic cylinders and manifolds
Channels5 ports / 2 positions
Switching time on12 ms; Switching time off: 15 ms
Media selectionCompressed air in accordance with ISO8573-1:2010 [7:4:4] (Lubricated operation possible)
Standard nominal flow rate400 l/min
Connection typeM7 internal threaded pneumatic ports
Housing materialDie-cast aluminum / Slot body: PPS-polymer
Mounting typeIntegrated mounting on CPV10 valve manifold block
Protection ratingIP 65
Weight75 g
Dimensions10 x 50 x 80 mm
Country of originGermany
HS Code8481.20.90
