Siemens OP 393 III 6ES5 393-0UA14 Operator Panel

Brand: Siemens

Model: OP 393 III

Part Number: 6ES5 393-0UA14

Type: Operator Panel

All tech specs
- Display: LCD character display, 4 lines x 20 characters (80 characters total), backlit
- Keyboard: Membrane keyboard, cursor keys, numeric keypad,
- Communication: MPI (Multi-Point Interface), point-to-point (PPI)
- Baud rates: Up to 1.5 Mbit/s
- Connection: 9-pin D-Sub connector (SUB-D) for PROFIBUS/MPI
- Number of messages: Up to 999 alarm/event messages, 999 text messages
- Languages: Multi-language support
- Functions: Alarm handling (with acknowledgement), message logging, trend display (simple), bar graphs, setpoint input, password protection, recipe handling (limited), print functions
- Configuration software: ProTool / ProTool/Lite or COMTEXT (for S5)
- Power consumption: Approx. 0.3 A
- Operating temperature: 0 to +45 °C
- Protection class: IP65
- Mounting: Front panel mounting (cut-out required), flush or surface mount
- Part of SIMATIC OP family: Legacy operator panel for S5 and early S7 systems, widely used in machine and process automation
- Status: Obsolete

Dimensions: 250 x 150 x 100 mm

Weight: 850 g

Country of origin: Germany

HS code: 853710
