Danfoss VLT Midi Drive - 134U2184

Brand: Danfoss

Model: VLT Midi Drive FC 280 (134U2184)

Type: Variable Frequency Drive (VFD) for AC motor control in industrial automation All

Material: Plastic/metal housing for IP20 chassis mounting and heat dissipation

Input Voltage: 3-phase 380-480 VAC (50/60 Hz, ±10% tolerance)

Output Voltage: 3-phase 0-Vin, 0-500Hz

Rated Power: 0.37 kW (0.5 HP)

Rated Current: 1.3 A (output, continuous)

Control Modes: V/f control; sensorless vector control (SVC) for precise torque/speed

Frequency Range: 0-400 Hz (output)

Overload Capacity: 150% for 60 seconds

Efficiency: >95% at full load

Built-in Functions: Brake chopper (integrated); EMC filter Class C1 (200V)/C2 (400V)

Programming: Control Panel with Display - supports Modbus RTU

Protection: Overvoltage, undervoltage, overcurrent, overload, overtemperature, short-circuit; coated PCB for harsh environments

Operating Temperature: 0°C to +45°C  full load; up to +55°C (131°F) with derating

Storage Temperature: -40°C to +70°C

Humidity: 5-95% RH (non-condensing)

Altitude: Up to 1000 m without derating

Standards: IEC/EN 61800-5-1; CE marked; EMC compliant (Class A)

Certification: CE; RoHS compliant; UL listed options

Features: Compact side-by-side mounting; auto-tuning; PID control; USB port for commissioning; suitable for HVAC, pumps, fans, and conveyors; easy replacement for VLT 2800 series

Dimensions: 170 x 70 x 210 mm

Weight: 2.5 kg

Country of Origin: Denmark

HS Code: 8504.40
