Pimatic

Pimatic OSC-160-16-502118-4 Compact Pneumatic Doctor Blade Oscillator

Pimatic OSC-160-16-502118-4 Compact Pneumatic Doctor Blade Oscillator

€1.391,50incl. VAT
€1.150,00 excl. VAT

Stock: 1
Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
BrandPimatic (Pimatic Oy)
ModelOSC-160-16
TypePneumatic Doctor Blade Oscillator (compact, lightweight pneumatic oscillator for doctor blades in paper machines)
Part numberOSC-160-16-502118-4
Technical specifications
Thrust force11 kN at 6 bar
Stroke length16 mm
Speed range3–5 strokes/min (back and forth); maximum 25 strokes/min
Air consumptionApprox. 4.2 Ndm³ per back-and-forth stroke at 6 bar
Operating mediumCompressed air, filtered (20 micron)
Pressure range2–10 bar
Temperature range+5°C to +150°C
MountingWithout mounting parts
MaterialsStainless steel AISI316; seals PTFE / Viton
Additional featuresEffective air cushioning eliminates vibration and dwell; no lubrication required; adjustable speed and stroke; compact and lightweight generation based on 20,000+ installations worldwide
StandardsDesigned for paper industry applications; compliant with relevant industrial pneumatic norms
Weight9.2 kg
Dimensions200 dia. x 130 mm
Country of originFinland
HS code8412.31
