Bosch / Rexroth

Rexroth A4V250EL2.0R102010 Variable Displacement Pump

Rexroth A4V250EL2.0R102010 Variable Displacement Pump

€10.278,95incl. VAT
€8.495,00 excl. VAT

Stock: 1
Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
Bosch Rexroth A4V250EL2.0R102010 Variable Displacement Pump Specifications
Product TypeAxial Piston Variable Displacement Pump
ManufacturerBosch Rexroth
ModelA4V250EL2.0R102010
MNRR909447613
Device ApplicationHydrostatic drives in closed circuits (e.g., industrial machinery, mobile equipment)
DesignAxial piston with swashplate
Nominal Displacement250 cm³/rev
Nominal Pressure350 bar
Maximum Pressure400 bar
FlowProportional to drive speed and displacement, infinitely variable
Control TypeEL (Electric proportional control with solenoid)
Rotation DirectionRight-hand (R)
Circuit TypeClosed circuit
Control DeviceProportional control for stepless flow adjustment via swashplate angle
Swashplate Adjustment0 to maximum angle, enabling smooth flow reversal over center
Integrated Boost PumpYes, acts as feed and control oil pump
Boost Pressure Relief ValveBuilt-in, limits maximum boost pressure
Crossline Relief ValvesIncluded, protects high-pressure side from overload and acts as boost inlet valves
Through DriveAvailable for mounting additional gear pump or variable pump
Shaft TypeSplined shaft
Mounting FlangeISO 3019-2 (metric)
Port ConnectionsMetric ports
Speed RangeTypically 500–2600 rpm
Fluid CompatibilityHydraulic fluids per DIN 51524 HLP, HFA, HFB, HFC;
Sealing MaterialTypically NBR (Nitrile Butadiene Rubber)
WeightApproximately 192 kg (based on similar A4VSO 250 model; confirm with supplier)
IP Degree of ProtectionIP54

Ambient Air Temperature for Operation: -20 to 70 °C

Ambient Air Temperature for Storage: -40 to 80 °C

Standards ComplianceISO 3019-2, DIN 51524
Special Features

Robust design for high-pressure industrial applications

Infinitely variable flow via swashplate adjustment

Integrated pressure cut-off as standard

Low noise emissions due to optimized swashplate design

HS Code8413.50.40
Country of OriginGermany
