Pepperl + Fuchs

Pepperl + Fuchs NBB20-U1-Z2 Inductive Sensor - 203044

Pepperl + Fuchs NBB20-U1-Z2 Inductive Sensor - 203044

€114,95incl. VAT
€95,00 excl. VAT

Stock: 2

Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
BrandPepperl + Fuchs (P+F)
ModelNBB20-U1-Z2
TypeInductive Sensor
Part number203044
Technical specifications
Sensing rangeRated operating distance sn = 20 mm (flush installation)
Output2-wire
Output polarityDC
Operating voltage5…60 V DC
Switching frequency0…250 Hz
Switching functionNormally open/closed (NO/NC)
Voltage drop≤ 5 V (at IL = 100 mA)
Load current IL2…200 mA
Off-state current Ir0…0.5 mA
Short-circuit protectionYes
Reverse polarity protectionReverse polarity tolerant
LED indicators2 yellow LEDs (switching state) with 360° visibility
Sensor headBidirectional and rotatable
ConnectionScrew terminals
Housing materialPA / metal with epoxy powder coating; sensing face PA; housing base plastic
Degree of protectionIP68 / IP69K
Ambient temperature-25…+85 °C
Additional featuresRotatable sensor head for flexible installation; robust construction for harsh environments; high EMC immunity
StandardsEN IEC 60947-5-2; cULus Listed; CCC approved
Weight280 g
Dimensions40 x 40 x 120 mm
Country of originGermany
HS code8536.50
