Siemens

siemens 3 ld2003-otk51 Switch 3 p

siemens 3 ld2003-otk51 Switch 3 p

€33,28incl. VAT
€27,50 excl. VAT

Stock: 9

Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
BrandSiemens
Model3LD2003-0TK51
TypeLoad switch (cam switch, 3-pole, for motor control and switching in industrial applications)
All Tech Specs
  MaterialThermoplastic enclosure (insulated for durability and arc resistance)
  Poles3 (3-pole configuration)
  Rated Current25 A (In, maximum continuous current)
  Rated Voltage690 V AC (Ue, maximum operating voltage)
  Rated Insulation Voltage1000 V (Ui)

  Rated Impulse Withstand Voltage: 8 kV (Uimp)

  Rated Short-Circuit Current10 kA (Icn, with gG/gL fuse)
  Utilization CategoryAC-21A (non-inductive loads); AC-23A (motor switching)
  Frequency50/60 Hz
  Contact MaterialSilver alloy (for reliable switching)
  Handle TypeBlack thumb grip (OTK51 variant)
  MountingFront panel or base mount (DIN rail optional)
  Degree of ProtectionIP65 (front); IP00 (terminals)
  Operating Temperature Range-25°C to +70°C (-13°F to +158°F)
  Mechanical Endurance>1 million operations
  Electrical Endurance>10,000 operations at rated load
  StandardsIEC/EN 60947-3; suitable for distribution boards and motor starters
  CertificationCE marked; RoHS compliant; CCC certified
  FeaturesModular design for accessories (auxiliary contacts, shunt trips); padlockable in OFF position; suitable for on/off control of motors up to 11 kW at 400 V
Dimension52 mm width x 48 mm height x 70 mm depth (2.05 in x 1.89 in x 2.76 in)
Weight0.3 kg (0.66 lbs)
Country of OriginGermany
HS Code8536.50 (switches for voltages >1,000 V)
