Woltmann Woltex WEN 50 Horizontal Water Meter

Woltmann Woltex WEN 50 Horizontal Water Meter

€1.028,50incl. VAT
€850,00 excl. VAT

Stock: 1

Tested & workingReally in stockWorldwide shipping12-month warranty
Ships from our own warehouse in Veen, the Netherlands
Order before 16:00 CET — shipped the same day
Worldwide shipping with track & trace
Questions? Contact our team
GearProduct description & specifications
BrandWoltmann (Woltmann Water Meters)
ModelWoltex WEN 50
TypeHorizontal Woltmann Water Meter
Part NumberWEN50GER
Technical Specs
Meter TypeHorizontal Woltmann Itron water meter with interchangeable measuring unit
Nominal Diameter (DN)50 mm
Nominal Flow Rate (Q3)15 m³/h
Starting Flow< 0.15 m³/h
Pressure Loss at Q3Δp < 0.25 bar (typical)
Maximum Operating Pressure20 bar
Temperature RangeCold water
Body MaterialCast iron with epoxy coating
Measuring UnitItron
Counter8-digit roller counter + pointer (totalizer in m³)
Protection ClassIP68
InstallationHorizontal (H)
ConnectionsFlanged PN 16
CompatibilityCyble pre equipped
Additional Features

  High accuracy across wide flow range

  Low starting flow and pressure loss

  Tamper-proof dry dial (protected from condensation)

  Replaceable measuring insert

  Long-term stability and low maintenance

  MID certified (OIML R49 / EN 14154)

Dimensions
Nominal Diameter (DN)50 mm
Length (lay length)200 mm
Flange Diameter165 mm (PN 16)
Height250 mm
Weight10 kg
Country of Origin France
HS Code 9028.20
